• RoHS
  • LEAD FREE
  • ANTI STATIC

HOT-AIR REWORK STATION
XFC-300

Equipped with Auto Profile Mode. Handles BGAs, CSPs and all SMDs using the preheater.

Package Contents

Forced Cool-down

On all zones with cool key

Hand Operation

Heater and vacuum switches on the handpiece

ON/OFF Interface

Controls external preheater

Accurate Temperature Control

With PID control

Various Profiles Available

Up to 19 profiles, each with 5 zones

Auto Profile

Can be set to the desired profile without a test

Either Auto profile or Repeat Profile function (PAT.). 5 zone profiles available:PREHEAT 1, PREHEAT 2, PREHEAT 3, REFLOW, and COOL. lUp to 19 profiles* can be saved for each of the 5 zones. One profile can be registered for HAND Mode. Accurate PID temperature control. Heater and Vacuum switches located on the handpiece for easy control. ON/OFF interface with Preheater (connection cable optional). Keypad lock and Offset functions. Instant cool down on all zones by pressing the COOL key.

*separate profiles with specific temperature and time settings can be pre-programmed for each of the 5 Zones

Product Specifications

Specifications

Model XFC-301 XFC-300 XFC-110
Voltage 220 – 240V AC 50/60Hz 220V, 230V, 240V AC 50/60Hz
Power Consumption 400 – 460W 470W
Power Cord Length 1.5m Inlet type
Temperature Setting Range 50 – 550°C 150 – 550°C
Insulation Resistance Over 10MΩ (500V DC)

Station Unit

Model XFC-301 XFC-300 XFC-110
Output Voltage 220 – 240V AC 220V, 230V, 240V AC
Air flow Meter Equipped
Air flow Volume 5 – 25L /min 5 – 25L /min
Auto-lift function Included
Modes 3 (Profile-Normal, Profile-Auto, Hand) 1 (Hand)
Temperature Profiles 5 Zones (Temperature and Time)
Profile Memory ( Auto, Normal )×19, HAND×1
Dimensions 200(W) × 230(H) × 265(D)mm 182(W) × 179(H) × 263(D)mm
Weight 7.6kg ( w/o cord ) 7.8kg ( w/o cord )
Accessory Connection Cable with Preheater, Handpiece Holder,
XVCW-SET
Handpiece Holder, XVCW-SET

Handpiece Unit

Model XFC-301 XFC-300 XFC-110
Voltage 220 – 240V AC 220V, 230V, 240V AC
Power Consumption 370 – 430W 400W
Heater Nichrome Heater
Hose length between Handpiece and Control Unit 1m
Vacuum Pickup Integrated into Handpiece
Length 220mm (w/o cord)
Weight 180g (w/o nozzle, cord)
